15.6 Inch 4 Serial Ports Low Power Android Industrial Panel PC DTP-T156-RK3288
15.6-inch fanless Android industrial panel PC powered by the RK3288 quad-core platform, featuring a Full HD touchscreen, 4 serial ports, Ethernet, USB, optional 4G connectivity, and flexible panel or VESA mounting for industrial equipment integration.
Product Type:Industrial Panel PCs
CPU:RK3288
Touch Screen Type:10-point Capacitive Touchscreen, 5-wire Resistive Touchscreen, Non-touch
Operating System:Android 7.1, optional Android 5.1 / 6.0 / 8.1, Linux Buildroot / Debian 9 / Ubuntu 18.04
Product Features:Fanless, Front IP65, Android, 4 Serial Ports, Wi-Fi, 4G Expandable, Panel Mount, VESA Mount
Ask a Product ManagerDownload Data Sheet
Product Details
Model: DTP-T156-RK3288
CPU:
Size: 15.6"
Touch Screen: Capacitive touchscreen, Resistive touchscreen, Non-touch screen
I/O Interface:
Operating system: Linux, Android
A 15.6″ Android industrial panel PC for touchscreen control and device connectivity.
Processing and system configuration
The DTP-T156-RK3288 uses the RK3288 platform with a maximum frequency of 1.8GHz. The standard configuration includes 2GB RAM and 16GB storage, while RAM can be configured up to 4GB and storage can be expanded to 32GB, 64GB or 128GB.
Display and touch options
The 15.6-inch Full HD TFT display provides a 1920 × 1080 resolution and wide viewing angles. Depending on the operator interface, the industrial panel PC can be configured with a 10-point capacitive touchscreen, a high-temperature 5-wire resistive touchscreen, or a non-touch display.
Industrial serial connectivity
Four serial ports are available for connecting industrial controllers, instruments and other serial devices. The standard configuration uses 1 × RS485 and 3 × RS232, and the serial configuration can support up to 2 × RS485 and 2 × RS232.
Wired and wireless connectivity
The DTP-T156-RK3288 provides a 10/100M Ethernet RJ45 port, 3 × USB 2.0, HDMI, Debug, TF card, SIM card, audio and DC input interfaces. Wi-Fi is supported, with 4G expansion available when wireless communication is required.
Android and Linux OS options
Android 7.1 is the standard operating system. Optional systems include Android 5.1, Android 6.0, Android 8.1, Linux Buildroot, Debian 9 and Ubuntu 18.04, allowing the software environment to be matched to the target application.
Installation and mechanical fit
The industrial panel PC measures 392 × 246 × 48 mm and uses a recommended panel cutout of 378 × 234 mm. It supports front-flush panel mounting and 75 × 75 mm VESA mounting, giving equipment builders two installation options.
Front protection
The front panel meets IP65 protection requirements. This protection rating applies to the front panel rather than the complete enclosure, so the installation design should account for where dust or water exposure may occur.
Product Specifications
Review the DTP-T156-RK3288 configuration before system integration.
| SPECIFICATION PARAMETER | ||
| System Parameters |
CPU | RK3288 |
| Frequency | Max base frequency,1.8GHz | |
| RAM | 2G,support up to 4GB | |
| Storage | 16G,support up to 32G、64G、128G | |
| I/O Interfaces | Network | 10/100M adaptive Ethernet RJ45 port |
| USB | 3*USB2.0 | |
| Serial Ports | 2*RS485/RS232;2*RS232 | |
| Other Interfaces | 1*HDMI,1*Debug,1*TF Card,1*SIM Card,1*AUDIO,1*DC IN | |
| Physical Specifications |
Dimensions(W*H*D) | 392mm*246mm*48mm |
| Cutout Dimensions(W*H) | 378mm*234mm(1.80/1.90mm lager than the actual cutout dimensions) | |
| Net Weight | 2.68kg | |
| Operating System | Operating System | Android 7.1,optional Android 5.1/6.0/8.1,Linux Buildroot/Debian 9/Ubuntu-18.04 |
| Power Supply |
Input Voltage | 12VDC(Customizable wide voltage available) |
| Max Power Consumption | 9.8W | |
| LCD Panel | Screen Type | 15.6″Full HD TFT |
| Resolution | 1920*1080 | |
| Maximum Colors | 16.2MB | |
| Backlight | LED | |
| Backlight MTBF(hours) | 30000hrs | |
| Pixel Pitch | 0.179*0.179 | |
| Luminance | 250cd/cm² | |
| Contrast Ratio | 800:1 | |
| Viewing Angle | (L)89/(R)89/(T)85/(B)85 | |
| Touch Screen |
Touch Screen Types | 10-point capacitive touch screen,High-temperature 5-wire resistive touch screen,Non-touch screen |
| Transmittance | >85% | |
| Response Time (stylus) | <5ms | |
| Surface Hardness | Mohs hardness 6H | |
| Touch Life | 250g/35,000,000 times | |
| Stroke Life | 250g/5,000,000 times | |
| Environmental Parameters |
Operation Temperature | 0～50°C(32~122°F) |
| Storage Temeperature | -20～60°C(-4～140°F) | |
| Relative Humidity | 10~95%RH@40℃,non-condensing | |
| Vibration During Operation | SSD applied:1.5 Grms,5～500 Hz,1 hr/axis | |
| Shock During Operation | SSD applied:10 G,Half-sine wave | |
| EMC | CE/FCC Class B | |
| Waterproofing | The front panel meets IP65 protection class | |
3D DRAWING & PDF DATA
Want to view the detailed product dime nsions?
Download 3D Drawingfaq
Frequently Asked Questions
What operating systems does the DTP-T156-RK3288 support?
Android 7.1 is the standard operating system. Optional operating systems include Android 5.1, Android 6.0, Android 8.1, Linux Buildroot, Debian 9 and Ubuntu 18.04.
What touchscreen options are available?
The industrial panel PC can be configured with a 10-point capacitive touchscreen, a high-temperature 5-wire resistive touchscreen, or a non-touch display.
Does it support Wi-Fi and 4G?
Yes. Wi-Fi wireless connectivity is supported, and 4G connectivity can be expanded as an option.
Does it support VESA mounting?
Yes. A 75 × 75 mm VESA mounting pattern is supported in addition to front-flush panel mounting.
What is the maximum power consumption?
The maximum power consumption specified in the datasheet is 9.8W.
